| Brand | Wintrone |
|---|---|
| Product Type | Orionis 8 VL - Low Entry Low Deck A/T 4x2 |
| Product Classification | Electric Bus 8 Meter |
| Application | Shuttle Bus |
| Range (80% / 100%) | 157 km / 196 km |
| Max Speed | 50 km/h |
| Max Gradeability | Up to 14% |
| Brake | Four Wheel Disc Brake With ABS |
| Length | 7,915 mm |
|---|---|
| Width | 2,100 mm |
| Height | 3,200 mm |
| Wheelbase | 3,850 mm |
| Front Overhang | 1,700 mm |
| Rear Overhang | 2,365 mm |
| Approach Angle | 9° |
| Departure Angle | 8° |
| Ground Clearance | 150 mm |
| Turning Radius | 7,025 mm |
| Suspension | Air Suspension |
| Curb Weight | 6,750 kg |
|---|---|
| Gross Weight | 8,000 kg |
| Type | Lithium Ferro Phosphate / LiFePO4 |
|---|---|
| Capacity | 132 kWh |
| Cooling | Liquid Cooling |
| Type | Permanent Magnet Synchronous Motor / PMSM |
|---|---|
| Power Rated / Peak | 100 / 170 kW |
| Max Torque | Up to 1,775 Nm |
| Type | Roof Mounted AC System |
|---|---|
| Cooling Capacity | 16 kW - 24 kW |
| Tire Size | 215 / 75 R17.5 |
|---|
| Capacity | Up to 23 Passengers |
|---|---|
| Passenger Door | 1. LH Single Inward Pneumatic Doors 2. RH & LH Single Center Inward Pneumatic Doors Disabled-friendly |
| Passenger Window | Sunergy Clear 6 mm |
| Port | CCS 2 |
|---|---|
| Charger | DC Charger |
| DC Charger | Floor-Mounted Dual Guns DC Charging |
| Charger Capacity | 90 kW |
| Charging Time | Approx. 2 hours / 0–100% |
| Voltage Rating - Input | 380 - 410 ±10% VAC 3 Phase |
| Voltage Rating - Output | 560 - 580 ±10% VDC |
